High measurement accuracy with integrated 24-bit ADC, and stable measurement up to 0.01 level
Integrated TRMS. External rectifier device is not needed for AC measurement
Highly integrated, single-chip solution
Integrated DSP unit supports digital calibration
High measurement accuracy with integrated 24-bit ADC, and stable measurement up to 0.01 level
Integrated TRMS. External rectifier device is not needed for AC measurement
Highly integrated, single-chip solution
Integrated DSP unit supports digital calibration
Measurement accuracy: up to 0.1 level
Display range: -19999-19999
Conversion rate is 3 times per second
Display mode: LCD/LED driver
AC rectification: Up to 2kHz
Communication mode: UART interface with integrated standard Modbus protocol
Alarm output: 4-channel isolated switch alarm output. Configuration is flexible
Operating voltage range: 2.4-3.6V
Calibration method: Digital calibration with internal memory can be used
